Rubber Magnet

Rubber Magnet
Rubber Magnet
Product Code : RM-06
Brand Name : MAGTECH
Product Description

Rubber Magnet

We are a noteworthy manufacturer, exporters and supplier of premium quality Rubber Magnet that is available with us in varied colors, lengths, widths and thicknesses. This magnet finds extensive use in advertising, promotional gifts, craft items and refrigerators. Offered magnet is precisely manufactured under the stern observation of our deft professionals by making use of quality assured raw material with the aid of extrusion and calendaring procedure in complete compliance with set industry standards. Apart from this, we are offering this Rubber Magnet at affordable price to our prestigious clients.

Key Features:

  • Durable
  • Non-porous
  • Weather resistance
  • Temperature stability
  • High magnetic strength
  • Very flexible & bendable
  • Resistance to demagnetization
  • Easily stamped, slit, punched & laminated
Key Specifications:
  • Available in self-adhesive backing system
  • The Color PVC-Laminated Flexible Magnet is available to the market in roll and sheet forms.
  • The magnet don’t crack or break and it can absorb sound and shocks. It makes it the perfect choice for a DC motor, which requires low noise.
  • The magnetic properties of Anisotorpic Flexible Magnet are 30% higher than isotropic flexible magnets, which are mainly provided with DC motors for various holdingapplications. The Isotropic Flexible Magnets is best suited for educational, promotional and advertising purposes.
  • The shape and dimension of the magnet is available in large rolls, large sheet or any other custom size.
  • There is an option of color printing in Isotropic Flexible Magnets and they can be tailored cut in the required shape.

Physical Properties
Parameter
Density 3.6 ~ 3.8 g/cm3
Hardness 92 ~ 97 Hs (A)
Tensile strength 58 ~ 78 kg/cm2
Elongation 125 ~ 165 %
Saturation Field Strength 10kOe 800kA/m
Temperature range -40 ~ +80°C
Flexibility No crack when twisting arounda testing bar with Ø20-Ø40
Twist No crack at twist with 180° twice



Dimension Range
Magnetic Strip by Injection  Width =2mm~40mm
Thick =1mm~8mm
Length <=60M Roll
Magnetic Sheet by Compression Length <=800mm
Width <=610mm
Thick =0.3mm~8.0mm
Magnetic Sheet Roll Form by Compression Width <=610mm
Thick =0.5mm~2.0mm
Length <=60M Roll
Magnetization Options
• Unilateral multipolar
• Unilateral bi-polar
• Thru thickness



Magnetic Properties
Material Isotropic/
Anisotropic
Remanence Coercivity Intrinsic
Coercivity
Max.
Energy Product
Grade Anisotropic Br (mT) Br (Gs) bHc (kA/m) bHc (Oe) iHc (kA/m) iHc (Oe) (BH) max (KJ/m) (BH) max (MGOe)
MR-7L Isotropic 165
+/-10
1,650
+/-100
108
+/-8
1,350
+/-100
132+/-8 1,650
+/-100
5.2
+/-0.4
0.65
+/-0.05
MR-7H Isotropic 170
+/-10
1,700
+/-100
112
+/-8
1,400
+/-100
136+/-8 1,700
+/-100
5.6
+/-0.4
0.70
+/-0.05
MR-10 Semi-aniso 220
+/-5
2,200
+/-50
136
+/-8
1,700
+/-100
160+/-8 2,000
+/-100
8.0
+/-0.4
1.00
+/-0.05
MR-12 Anisotropic 245
+/-5
2,450
+/-50
140
+/-8
1,750
+/-100
148+/-8 1,850
+/-100
11.2
+/-0.4
1.40
+/-0.05
MR-12BH Anisotropic 247.5
+/-2.5
2,475
+/-25
168
+/-8
2,100
+/-100
224+/-8 2,800
+/-100
12.0
+/-0.4
1.50
+/-0.05
